Muso Square SD

Muso Square SD
Muso Square SD

Fiche technique

Merk – Marque: Tecnico
Materiaal – Materiaux: Polycarbonate
Type: Opbouw / Apparent
Afmetingen armatuur – Dimensions armature: Ø280mm / Ø330mm / Ø400mm
Kleur – Couleur: Wit-Blanc
Reflector – Reflecteur: Opaal / Opal
Uitrusting – Equipement: LED
Systeemvermogen – Puissance de système: 18W / 24W / 36W
Kelvin graden – Degré Kelvin: 3000°K
Lumen:

18W: 1750 lm

24W: 2270 lm

36W: 3200 lm

RA – CRI: >80
Afkoeling – Refroidissement: Passief – Passif
Voorschakelapp – Ballast: LED driver (Inclu.)
Voeding – Alimentation: 220-240V 50/60Hz
Bescherming – Protection: IP54 / IK08
Norm – Norme: CE EN60598-1
CIE fluxcode: Op aanvraag – Sur demande
Optie – Option Push

Motion detector with 8m detection radius, switch-on level <40lx, 90 sec. holding time (Only for 24W)

Emergency light: 2W, battery life aprox. 3h. (Only for 18W)

Dessin technique
